360 birdview system
- 1080P full HD video input and output, real-time;
- 3D/2D switchable
- Compatible with Ai or ultrasonic sensor
- Automatic calibration
- 512 SD card or 1T HDD optional
Features
- - 4CH/6CH 1080P
- - With A.i. features optional, ADAS,DSM,BSD
- - Compatible with Radar/Ultrasonic sensor
- - Suitable for Con-truck, Logistic truck and Forklift.
Technical Parameters
| Input video | Max.4CH×1080P@25fps/1080P@30fps |
| Display mode | 2D/3D |
| Resolution | 1080P |
| Output Refresh rate | 25/30fps |
| Storage | Max. 512GB SD card or 1TB HDD |
| Video stream | 4M/2M |
| Operating voltage | 10-32V |
| Operating voltage range for external trigger signals | 10-32V |
| Operating electric current | <2A/12V |
| Operating temperature | -20℃-70℃ |
| Storage temperature | –40℃ ~85℃ |
